Product Description
Lewmar H2 Gypsy Drum 24V w/ 3/8" (10mm) Kit
Kits include: Built-in-dual-direction contactor, Breaker and Rocker Switch
Specifications
Model - H3
Motor Power Watts - 1000W
Normal Current Draw - 60A
Circuit Breaker - 90A slow blow
Max Pull - 2248 lbs. (1020 kg)
Max Line Speed - 98ft/min (30m/min
Working Load - 535 lbs. (243 kg)
Normal Line Speed - 66 ft. (20m)
Weight Gypsy/Drum - 56 lbs. (25.5 kg)
Gypsy Specifications
Gypsy Number - 506
Size - 3/8" (10mm)
Chain Description - 3/8" BBB, 10mm DIN 766, Lewmar 9.5 G40
Rope Description - 9/16"-5/8" (14-16mm) 3-strand and 8-plait (5/8" Only)
Cable Sizes
Voltage - 24V
Length of Cable Run - 0'-23'(0-7m) 23'-50'(7-15m) 8 AWG (10mm²) 6 AWG (16mm²)
Switch Wiring - 16 AWG (1.5mm²)
Current rating for Switch Wire - 5A
