Product Description
Wichard 4 9/64" Swivel w/ Clevis Pin & Ball Bearing - Black
Features
Weight - 0.617 lbs (280 g)
Length - 4 9/64" (105mm)
Working Load - 7050 lbs (3200 kg)
Breaking Load - 13220 lbs (6000 kg)
A - 3/4" (19mm)
B - 1 7/32" (31mm)
C - 45/64" (18mm)
Diameter - 7/16" (11mm)
Description
HR forged swivel (17.4 Ph) with only one opening side and one eye
With ball bearings for an easier rotation
Outstanding working and breaking loads
Applications
Link two pieces which have different rotation
For applications requiring an easier rotation
Material
HR stainless steel 17.4 PH
