Lewmar Size 18 Low Profile Self Supporting Round Hatch

Item #

39918030

Usually ships within 1-3 days

Product Description

Lewmar Size 18 Low Profile Self Supporting Round Hatch

All sizes suitable for CE Area 2 (Deck, Coachroof, Cockpit and Transom).

Mounting Instructions:

Fit to a flat surface with a maximum tolerance of +/- 1mm. Fastening size at hinge section use (M6 / 1/4"). Fastening size for lower frame use 5mm CSK screw No.10 UNC 2 BA.

Specifications

  • Support System - Self Supporting

  • Lower Frame (in) - 9/16

  • Acrylic Color - Smoke Grey

  • Hatch Weight (lb) - 8.4

  • Acrylic Window Thickness (in) - 5/16

    Dimensions

  • Diameter Ø (in) - 19 15/16

  • Height Z (in) - 1

  • Hinge Length HX (in) - 19 7/16

  • Hinge Width HY (in) - 5 9/16

  • Cut-Out Diameter Ø1 (in) - 16 9/16
